2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube

Thanks for your kindly hospitality. Your company is very professional , we will have nice cooperation in the near future.

—— Rose

I'm Online Chat Now

2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube

2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube
2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube

Large Image :  2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube

Product Details:
Place of Origin: WUXI, CHINA
Brand Name: JINHUA
Model Number: JH-330
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: USD+2000-50000+Unit
Packaging Details: Wooden Box Package
Delivery Time: 15-60 days
Payment Terms: T/T
Supply Ability: 30+Units+Per Month
Detailed Product Description
Machine Type: Pipe Cladding Machine, Pipe Inner Hardfacing Machine, Pipe Inner Surface Overlay Welding Machine Condition: New
Material: Carbon Steel, Alloy Steel After-Sales Service: Engineers Available To Service Machinery Overseas, Field Installation, Commissioning And Training, Video Technical Support, Field Maintenance And Repair Service
Warranty: 1 Year Color: Yellow, Blue, Customized
Voltage: 220V/380V/400V, 220V/380V/415V/440V/customized, 220V50HZ1P, Optional, 380V Or 220V/60HZ /3P (Also According To Your Local Voltage) Industries: Cement, Steel, Mining, Power, Security, Agriculture, Recycling
High Light:

2500Kgs Pipe Hardfacing Machine

,

800mm Pipe Hardfacing equipment

,

800mm Overlay Welding Machine

Automatic Hardfacing Machine for Wear Resistance Tube, Automaitc Overlay Welding Machine for Wear Resistance Pipe



1. Machine Introduction

90-Degree Elbow Cladding is a process of weld overlay of stainless steel inside 90-degree pipe elbow. JINHUA offers an unique system for 90-degree elbow cladding with Hot Wire TIG using a patented sector-wise cladding forconsistent quality and high productivity.



A STAINLESS-STEEL-CLAD metal or alloy is a composite product consisting of a thin layer of stainless steel in the form of a veneer integrally bonded to one or both surfaces of the substrate. The principal object of such a product is to com-bine, at low cost, the desirable properties of the stainless steel and the backing material for applications where full-gage alloy construction is notrequired. While the stainless cladding furnishes the necessary resistance to corrosion, abrasion, or oxidation, the backing material contributes structural strength and improves the fabricability and thermal conductivity of the composite. Stainless-steel-clad metals can be produced in plate, strip, tube, rod, and wire form.







2. Machine Parameter



Bend angle of the pipe 90 Deg
Inner diameter range 174 ~ 800 mm
(160 mm after cladding)
Bending radius range 450 ~ 1000 mm
Maximum job weight 2500 Kgs
Mains supply 380±10%V AC, 3Ph, 50Hz
Ambient temperature -5 to +45 Degree
Relative humidity 20 ~ 90%
Flammable Gas NONE
Corrosive Gas NONE
Shielding gas AIr (purity ~ 99.99%
Work site Indoor





Diameter Range of Overlay Welding Φ150-3000mm
Maximum Overlay Welding Length 6000 mm
Overlay Welding Speed 0-250mm /min
Overlay Welding Thickness 3-6mm
Allowable Weight 2.0T
Maximum Power 28.5Kw
Water Cooling Control System Variable frequency circulating water cooling
Control System The control system adopts Variable frequency + digital system control
Idle Travel Speed 0-7000mm/min
Allowable Material for Overlay Welding Q235 Q345
Elevation of Overlay Welding Torch 0-100mm
Elevating Mode of Overlay Welding Torch Manual mechanical lifting
Precision Standard of Whole Machine Conforming to JB/T5102-1999
Linear Positioning Accuracy ±1mm/5m
Velocity Error ±2%



3. Pictures

2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube 0

2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube 1



2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube 2



2500Kgs 800mm Pipe Cladding Machine For Wear Resistance Tube 3
